0.12-3mm Thick Cold Rolled Steel Sheet DC01 EN 10130

Whether you need DC01 steel sheets with premium surface treatment, durable DC01 galvanized steel coils, corrosion-resistant DC01 galvanized steel pipes, or DC01 pre-coated galvanized steel (PPGI) with good coating adhesion, we can provide you with the most suitable solution.

Alloy DC01 BS En 10130 DC01-07 Carbon Steel Sheet EN 10130 DC01 DIN EN10130 Cold Rolled Steel SPCC St12 EN10130 DC01 0.12-3mm Cold Rolled Steel SPCC St12 EN10130 DC01 Q195/Q215 0.12-3mm Cold Rolled Steel EN 10130 DC01 Steel 1.0330+ZE Material DC01, 1.5 mm Thick, Carbon Steel Sheet Sheet DC01 AM 2500x1250x2.00 mm

What is EN 10130 DC01 sheet metal?

DC01 steel (1.0330 material) is a European standard cold-rolled quality low-carbon steel flat product for cold forming. In BS and DIN EN 10130 standard, it contains 5 other steel grades: DC03 (1.0347), DC04 (1.0338), DC05 (1.0312), DC06 ( 1.0873) and DC07 (1.0898), the surface quality is divided into 2 types: DC01-A and DC01-B. In addition, this steel is also used under electrogalvanizing conditions. The designation of the steel is DC01+ZE (or 1.0330+ZE), and the standard is EN 10152.

Specification Parameters
Basic Information

Chemical Composition of En 10130 DC01 Cold Steel Coil

The DC01 steel chemical composition is listed in the following table based on ladle analysis.

Country (Region) Standard Chemical Composition (ladle analysis), %, ≤ Surface quality Deoxidation Classification
Steel name (Steel number) C Mn P S
European Union EN 10130 DC01 (1.0330) 0.12 0,60 0,045 0,045 A, B Manufacturer’s discretion Non-alloy quality steel
EN 10152 DC01+ZE (1.0330+ZE) A, B
EN 10139 DC01-C390, C340, C440, C490, C590, C690 –

Notes:

  • EN 10130 – Cold rolled low carbon steel flat products;
  • EN 10152 – Electrolytically zinc coated cold rolled steel flat products.
  • EN 10139 – Cold rolled uncoated low carbon steel narrow strip.

DC01+ZE Steel Mechanical Properties

The table below lists DC01+ZE steel mechanical properties.

Mechanical properties, Part-1
Country (Region) Standard Steel name (Steel number) Yield strength (MPa), 0.2 % offset Tensile strength (MPa) Elongation, ≥ % Surface quality Absence of stretcher strain marks
European Union EN 10130 DC01 (1.0330) 140 (assumed) -280 270-410 28 A, B –
EN 10152 DC01+ZE (1.0330+ZE) 3 months

Notes:

Yield strength: When the thickness is ≤0.7 mm but >0.5 mm, the yield strength value should be increased by 20 MPa. For thicknesses ≤0.5 mm, the value should be increased by 40 MPa.

Elongation: When the thickness is ≤0.7 mm but >0.5 mm, the minimum value of elongation should be reduced by 2 units. For thicknesses ≤0.5 mm, the minimum value shall be reduced by 4 units.

Mechanical properties, Part-2
Standard Designation Delivery condition Symbol Yield strength (MPa), 0.2 % offset Tensile strength (MPa) Elongation, A80, ≥ % Elongation, A50, ≥ % Hardness, HV Validity of the mechanical properties
EN 10139 DC01 (1.0330) Annealed A – 270 – 390 28 30 ≤ 105 3 months
Skin passed LC ≤ 280 270 – 410 28 30 ≤ 115
Work hardened C290 200 – 380 290 – 430 18 20 95-125
C340 ≥ 250 340 – 490 Not required Not required 105-155
C390 ≥ 310 390 – 540 117-172
C440 ≥ 360 440 – 590 135-185
C490 ≥ 420 490 – 640 155-200
C590 ≥ 520 590 – 740 185-225
C690 ≥ 630 ≥ 690 ≥ 215

Electrolytic Zinc Coatings

Coating Designation Nominal zinc coating values for each surface Minimum zinc coating values for each surface
Thickness, µm Mass, g/m² Thickness, µm Mass, g/m²
ZE25/25 2,5 18 1,7 12
ZE50/50 5,0 36 4,1 29
ZE75/75 7,5 54 6,6 47
ZE100/100 10,0 72 9,1 65
