ABS DH36 Steel Plate

Product Name: DH36 Marine Steel Shipbuilding Steel Plate

Color:Natural,Painting

Length: 2440 mm, 5800 mm, 6000 mm, 8000 mm

Thickness: 1.5 mm-160 mm

Classification society:CCS ABS GL BV DNV KDK LR

Standard AISI,ASTM,DIN,JIS,GB,SUS,EN,etc.

ABS DH36 Steel Plate Supplier

ABS-certified material serves the shipbuilding industry with some of the most high-performance steel available, with properties optimized to meet all the challenges associated with shipbuilding and offshore fabrication projects. GNEE Steel carries a full inventory of the H-series shipbuilding steels, including AH36, EH36, and DH36 in the most widely used formats.

DH36 steel is designed to resist the harsh saline conditions of marine environments, and DH36 steel plate is typically employed for fabricating ship’s hulls, bulkheads, upper decks and hatch covers. DH36 steel contains elements such as Nb, V, Ti, and other alloying metals, and micro-alloying technology is used to enhance its mechanical properties. The controlled rolling process refines the grain of the alloy, and improves durability. Simply put, the H series of shipbuilding-grade plate offers some of the highest performance steel in the world.

Features of ABS DH 36 steel plate

ABS DH 36 steel plate is a resilient material that’s easy to fabricate. It’s American Bureau of Shipping-certified and designed for maritime structures. Typical characteristics of this steel plate grade include:

  • Superior toughness
  • Resists corrosion
  • Strong processability
  • High strength
  • Good weldability
  • Strong machineability

What is ABS DH36 equivalent to?

Equivalent steel grade of AB/DH36

DNV

GL

LR

BV

CCS

NK

KR

RINA

NV D36

GL-D36

LR/DH36

BV/DH36

CCS/D36

K D36

R D36

RI/D36

Specification Parameters
Basic Information

AB/DH36 High-Strength Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

Al

N

AB/DH36

0.18

0.1-0.50

0.90-1.6

0.035

0.035

0.015

Nb

V

Ti

Cu

Cr

Ni

Mo

0.02-0.05

0.05-0.10

0.02

0.35

0.2

0.4

0.08

Crack Sensitivity:  Pcm = (C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent:  Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%



AB/DH36 high strength property

Grade

Mechanical Property

Charpy V Impact Test

Thickness

Yield

Tensile

Elongation

Degree

Energy 1

Energy 2

AB/DH36

mm

Min Mpa

Mpa

Min  %

-20

J

J

t≤50

355

490-620

21%

24

34

50<t≤70

355

490-620

21%

27

41

70<t≤100

355

490-620

21%

34

50

Note: Energy 1 is transverse impact test, Energy 2 is longitudinal



Service Support
ABS DH36 Steel Plate

FAQ

Q:Why don’t steel ships rust?

A:Steel ships are protected from rust by coatings, such as paint, and cathodic protection systems that prevent corrosion.

Q:What steel is used in shipbuilding?

A:Shipbuilding primarily uses high-strength low-alloy steels, including grades like AH36, DH36, and EH36.

Q:What grade of steel is used in shipbuilding?

A:Common grades used in shipbuilding are AH36, DH36, and EH36.

Q:What is the difference between EH36 and DH36 steel?

A:EH36 steel has higher strength and toughness compared to DH36 steel, making it suitable for more demanding applications.

Q:What is the steel grade DH36 equivalent to?

A:DH36 steel is equivalent to ASTM A131 Grade DH36 and can be compared to other international standards like ABS Grade DH36.

Q:What does ABS stand for?

A:It stands for American Bureau of Shipping and indicates that the grade was certified by the Bureau.

Q:What is the difference between ABS A/B and ABS AH36/DH36/EH36/FH36?

A:Ordinary-strength steel comes in a various number of grades, including A, B, D, E, and F. Each of these grades have different alloy chemical ingredients and a different fracture toughness.
