Home > Steel Pipe> API 5L LSAW Thick Wall Pipe
API 5L LSAW Thick Wall Pipe image
  • API 5L LSAW Thick Wall Pipe image 1
  • API 5L LSAW Thick Wall Pipe image 2
  • API 5L LSAW Thick Wall Pipe image 3
  • API 5L LSAW Thick Wall Pipe image 4
  • API 5L LSAW Thick Wall Pipe image 5
  • API 5L LSAW Thick Wall Pipe image 6

API 5L LSAW Thick Wall Pipe

API 5L LSAW pipe is manufactured by bending and welding the steel plate in a longitudinal direction. These pipes are known for their high-quality weld seam and ability to withstand high pressure and stress.

api 5l seamless pipe api seamless pipe api 5l x65 api 5l
Reference Price: $600
inquiry now

API 5L LSAW Thick Wall Pipe

API 5L LSAW Pipe, which stands for American Petroleum Institute specification 5L, is widely used in the oil and gas industry for conveying gas, water, and oil. These pipes come in various forms of welded construction, including Longitudinal Submerged Arc Welding (LSAW), Double Submerged Arc Welding (DSAW), and Helical Submerged Arc Welding (HSAW), each with its unique characteristics and applications. and API 5L specification covers seamless and welded steel line pipe.

It includes standard-weight and extra-strong threaded line pipe. It includes standard-weight and extra-strong threaded line pipe and pipe fittings. The purpose of this specification is to provide standards for pipe suitable for use in conveying gas, water, and oil in both the oil and natural gas industries. Grades covered by this specification are A25, A, B (and the following “X” Grades) x42,x46,x52,x60,x65,x70. The two-digit number following the “X” indicates the minimum yield strength (in 000’s psi) of pipe produced to this grade.



API 5L LSAW Pipe

  • API 5L LSAW pipe is manufactured by bending and welding the steel plate in a longitudinal direction.
  • These pipes are known for their high-quality weld seam and ability to withstand high pressure and stress.
  • API 5L LSAW pipes are commonly used for transporting hydrocarbons over long distances, such as in oil and gas transmission pipelines.

Material Grades

High Temperature Seamless Pipe ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B
Heat Exchanger Seamless Tube ASTM A179
Low Temperature Seamless Pipe ASTM A333 Gr. 3/6
Low Temperature Seamless Tube ASTM A334 Gr. 6
High Yield Seamless Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
High Yield Seamless Pipe ISO 3183 Gr. L245, L290, L320, L360, L390, L415, L450, L485
Atmospheric & Low Temp EFW Pipes ASTM A671 Gr. CC60/CC65/CC70
High Pressure & Moderate Temp EFW Pipes ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70
High Yield ERW/SAW Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
High Yield ERW/SAW Pipe ISO 3183 Gr. L245, L290, L320, L360, L390, L415, L450, L485
  • Quality Level : PSL1 and PSL2
  • Grade： Gr.B/BR/BN/BQ/BM
  • Outer Diameter: 219mm-1820mm
  • Wall Thickness: 5.0mm-50mm
  • Specification Acc to API5L /ISO 3183
  • Quality Level : PSL1 and PSL2
  • Grade： Gr.B/BR/BN/BQ/BM
  • Outer Diameter: 219mm-1820mm
  • Wall Thickness: 5.0mm-50mm
  • Length: 6mtr-18mtr
  • End: square ends (straight cut, saw cut, and torch cut). or beveled for welding

GNEE STEEL Group was built in year 2018 with registered capital of 30,000,000RMB, and we have been in the steel products industries for more than 15 years. The group is located in Anyang City, next to capital of Henan Province, and it enjoy good transportation environment of 3 hours to nearest port and 1 hour reaching the airport.

Customer Case

API 5L pipe specifications

Types of Packaging

  • – Bundles (hexagonal)
  • – Wooden Boxes
  • – Crates (steel/wooden)
  • – Special crates for U-Bend tubes with each radius separated
  • – Packaging for API 5L Grade B, x42,x46,x52,X56,x56,x60,x70 Carbon Steel LSAW Pipe as per customer’s requirements

Api 5l lsaw thick wall pipe price

Specification Parameters
Basic Information

Chemical Composition of API 5L Casing Tube

PSL 1
GRADE Chemical Composition Mechanical Property
C (Max) Mn (Max) P (Max) S (Max) TENSILE ( Min ) YIELD ( Min )
Psi X 1000 Mpa Psi X 1000 Mpa
A25 CL I 0.21 0.60 0.030 0.030 45 310 25 172
CL II 0.21 0.60 0.030 0.030
A 0.22 0.90 0.030 0.030 48 331 30 207
B 0.26 1.20 0.030 0.030 60 414 35 241
X42 0.26 1.30 0.030 0.030 60 414 42 290
X46 0.26 1.40 0.030 0.030 63 434 46 317
X52 0.26 1.40 0.030 0.030 66 455 52 359
X56 0.26 1.40 0.030 0.030 71 490 56 386
X60 0.26 1.40 0.030 0.030 75 517 60 414
X65 0.26 1.45 0.030 0.030 77 531 65 448
X70 0.26 1.65 0.030 0.030 82 565 70 483

Chemical Composition of API 5L OCTG Tube

PSL 2
GRADE Chemical Composition Mechanical Property
C
(Max)		 Mn
(Max)		 P
(Max)		 S
(Max)		 Tensile Yield C. E. IMPACT ENERGY
Psi x 1000 Mpa Psi x 1000 Mpa PCM IIW J FT/LB
B 0.22 1.20 0.025 0.015 60 – 110 414 – 758 35 – 65 241 – 448 0.25 0.43 T/L 27/41 T/L 20/30
X42 0.22 1.30 0.025 0.015 60 – 110 414 – 758 42 – 72 290 – 496 0.25 0.43 T/L 27/41 T/L 20/30
X46 0.22 1.40 0.025 0.015 63 – 110 434 – 758 46 – 76 317 – 524 0.25 0.43 T/L 27/41 T/L 20/30
X52 0.22 1.40 0.025 0.015 66 – 110 455 – 758 52 – 77 359 – 531 0.25 0.43 T/L 27/41 T/L 20/30
X56 0.22 1.40 0.025 0.015 71 – 110 490 – 758 56 – 79 386 – 544 0.25 0.43 T/L 27/41 T/L 20/30
X60 0.22 1.40 0.025 0.015 75 – 110 517 – 758 60 – 82 414 – 565 0.25 0.43 T/L 27/41 T/L 20/30
X65 0.22 1.45 0.025 0.015 77 – 110 531 – 758 65 – 82 448 – 565 0.25 0.43 T/L 27/41 T/L 20/30
X70 0.22 1.65 0.025 0.015 82 – 110 565 – 758 70 – 82 483 – 565 0.25 0.43 T/L 27/41 T/L 20/30
X80 0.22 1.90 0.025 0.015 90 – 120 621 – 827 80 – 102 552 – 705 0.25 0.43 T/L 27/41 T/L 20/30

API 5L Line Pipe Physical Properties

API 5L Grade Yield Strength
min.
(ksi)		 Tensile Strength
min.
(ksi)		 Yield to Tensile Ratio
(max.)		 Elongation
min.
%1
A 30 48 0.93 28
B 35 60 0.93 23
X42 42 60 0.93 23
X46 46 63 0.93 22
X52 52 66 0.93 21
X56 56 71 0.93 19
X60 60 75 0.93 19
X65 65 77 0.93 18
X70 70 82 0.93 17
X80 80 90 0.93 16
Service Support
API 5L LSAW Thick Wall Pipe

FAQ

1. Q: Are you a factory or trading company?
A: We are professional manufacturer for steel pipe, and our company also is a very professional a trade company for steel products.we can also provide a wide range of steel products.

2. Q: Can I get samples before order ?
A: Yes, of course. Usually our samples are free. we can produce by your samples or technical drawings.

3. Q:what is your delivery time ?
A: Our delivery time is about one week, timing according to the number of customers.

4. Q:What is your payment terms?
A: Our usual payment methods are T/T, L/C, D/A, D/P, Western Union, MoneyGram, payment methods can be customized according to customer requirements.

5.Q:What do your factory do regarding quality control?
A: We have obtained ISO, CE and other certifications. From materials to products, we check every process to maintain good quality.
