AR 600 Extreme Wear Resistance Steel Plates

AR 600 plates are produced by using good quality of alloy complying latest technology and machinery it leads in offering various attributes. All these have made the product to be very much higher in demand and the right choice for numerous critical applications. The product also withstands heavy loads and high-temperature atmosphere.

AR 600 Plates AR 600 Plate AR 600 Wear Plates AR 600 Abrasion Resistant Steel Plates Hb 600 Bhn Plate AR 600lt Plates Ar600 Plates AR 600 Low-temperature Steel Plates Hb 600 Bhn Plate 600 Hbw Plates AR 600 Liner Plates Abrasion Resistant Creusabro 600 Steel Plates Dillidur 600 Wear Plate Material

Introduction
Parameters
Service

What is AR600 Steel?

AR600 steel is a high-performance, abrasion-resistant material engineered for the most demanding wear applications. With a hardness range of 580-670 BHN, AR600 boasts exceptional resistance to sliding abrasion thanks to its unique chemistry, including a high carbon content. This makes it an ideal choice for industries such as aggregate, mining, and manufacturing that face significant wear and tear on their equipment.

AR 600 Plates Specification

AR 600 Plate Thickness	8 – 65 mm
AR 600 Wear Plates Width	Up to 2900 mm
600 HBW plate production	Hot-Rolled (HR) / Cold-Rolled (CR)
AR 600 Abrasion Resistant Steel Plates Length	Up to 14630 mm
AR 600 Liner Plates Heat Treatment	N, Q+T
AR 600LT plates Surface Paint	EP, PE, HDP, SMP, PVDF
EN 10051 EN 10029 AR 600 Plate Material	AR 600, HB 600 Steel Plate, AR 600 Abrasion Resistant Steel Plates, AR 600 Wear Resistant Plates

AR 600 Plates Application Industries

Some of the key applications are:

Screen Plates—Chute Liners
Conveyor Buckets
Cutting Edges
Ripper Tyne
Hoppers
Ore Scrapers
Slide conveyor
Dump trucks
Slurry Pipe Systems

Specification Parameters

Chemical max composition AR 600

Plate Thickness	C	Si	Mn	P	S	Cr	Ni	Mo	B	CEV	CET
mm	Max	Max	Max	Max	Max	Max	Max	Max	ppm	typical	typical
8 – 30	0.45	0.70	1.00	0.015	0.010	1.2	2.0	0.80	0.004	0.73	0.55
30.1 – 50	0.47	0.70	1.00	0.015	0.010	1.2	2.0	0.80	0.004	0.84	0.59

CEV = C+Mn/6+(Cr+Mo+V)/5+(Cu+Ni)/15
CET = C + （Mn+Mo）/10+( Cr+ Cu)/20+ Ni/40

AR 600 Maximum Carbon equivalent CET (CEV)

Thickness (mm)	8.00 – 24.99	25.00 – 65.00
Max CET(CEV)	0.58 (0.76)	0.61 (0.87)

Mechanical Properties for AR 600 High Tensile Plate

Hardness [HBW], guarantee	Impact toughness, typical 20 mm	Yield strength	Tensile strength,	Elongation
570 – 640	20 J/-40°C (-40 F)	1650 N/mm²	2000 N/mm²	7 %
