ASTM A131 E Shipbuilding Steel

Steel Standard:ASTM A131/A131M

Rolling Type:Shipbuilding steel plate,Platform steel plate

Thickness:3mm-300mm

Width:1500mm-4200mm

Length:3000mm-18000mm

Heat Treatment:As Rolled/Control-rolled/TMCP/Normalised

ASTM A131 E Shipbuilding Steel Supplier

Shipbuilding A131 Grade E,A131GrE steel plate,A131GrE steel sheet mainly be used in below minus 40 centigree ocean situiation.

Characteristic of ASTM A131 E steel plate ?

ASTM A131 E steel plate has enough strength to resist fracture and deformation under external forces, at same time, ASTM A131 E steel plate also has good plasticity, so that it will not be destroyed under external force with plastic deformation. ASTM A131 E steel plate also has good resistance to impact load and brittle failure.

Application

The applicable range of ASTM A131 E Shipbuilding Steel is primarily in the shipbuilding and marine engineering sectors. It is used for constructing different types of ships, including cargo ships, passenger vessels, and naval ships. The steel is suitable for fabricating hull plates, decks, bulkheads, and other structural elements. Additionally, it can also be employed in offshore structures such as oil rigs and platforms that are subject to similar harsh marine environments. Its combination of strength, weldability, and corrosion resistance makes ASTM A131 E Shipbuilding Steel an ideal choice for any marine-related construction project, ensuring the reliability and longevity of the structures in the demanding world of the sea.

Specification Parameters
Basic Information

ASTM A131 Grade E offshore steel plate chemical composition:

C %

Si %

Mn .Min%

P %

S %

C+Mn/6

0.18

0.10-0.35

0.70

0.035

0.035

0.40

ASTM A131 Grade E offshore steel plate mechanical property:

Yield Strength (Mpa)

Tensile Strength
(MPa)

Elongation in 8 in.[200mm]
(%)

Elongation in 8 in.[200mm]
(%)

Impact Energy
(J)

Test Temperature(°C)

≥235

400-520

≥21

≥24

27

-40

Service Support
ASTM A131 E Shipbuilding Steel

Technical Requirements & Additional Services for A131 GrC Steel Plate:

 High tension test
 Z-Test (Z15,Z25,Z35)
 Low temperature impacting test
 Ultrasonic test under ASTM A435,A577,A578
 Cetificated by ABS,LR,BV,DNV-GL,KR,NK,CCS,RINA
 Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
 Shot blasting and Painting,Cutting and welding as per end user’s demands
