ASTM A131 Grade A Steel Plate

Steel Standard:ASTM A131/A131M

Rolling Type:Shipbuilding steel plate,Platform steel plate

Thickness:3mm-300mm

Width:1500mm-4200mm

Length:3000mm-18000mm

Heat Treatment:As Rolled/Control-rolled/TMCP/Normalised

ASTM A131 Grade A Steel Plate Supplier and Manufacturer

A131 Grade A steel plate is common strength marine grade steel plate. It is mainly used to build hull of vessels and ship body. The Air rolled and Control Rolled are common rolling states for ASTM A131 grade A steel plate with equal and below 40mm thickness. And for ASTM A131 grade A steel plate whose thickness above 40mm, the heat treatment shall be Normalised or TMCP, so as to improve the A131 grade A steel plate strength.



  • Steel Standard:ASTM A131/A131M
  • Rolling Type:Shipbuilding steel plate,Platform steel plate
  • Thickness:3mm-300mm
  • Width:1500mm-4200mm
  • Length:3000mm-18000mm
  • Heat Treatment:As Rolled/Control-rolled/TMCP/Normalised





Specification Parameters
Basic Information

Mechanical property for A131GrA steel plate:

Yield strength (≥Mpa) Tensile strength (Mpa) Elongation in ≥,%
235 400-520 200mm 50mm
21 24


Chemical composition for A131GrA steel plate (Heat Analysis Max%)

Main chemical elements composition of A131GrA steel plate
C Si Mn P S
0.21 0.50 2.5×C 0.035 0.035



Service Support
ASTM A131 Grade A Steel Plate

Technical Requirements & Additional Services for A131GrA steel plate:

 High tension test
 Z-Test (Z15,Z25,Z35)
 Low temperature impacting test
 Ultrasonic test under ASTM A435,A577,A578
 Cetificated by ABS,LR,BV,DNV-GL,KR,NK,CCS,RINA
 Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
 Shot blasting and Painting,Cutting and welding as per end user’s demands
