BV-AH36 shipbuilding steel plate

Steel Standard:BV (Bureau Veritas)

Rolling Type:Shipbuilding steel plate,High tension ship plate

Thickness:3mm-250mm

Width:1200mm-4200mm

Length:3000mm-18000mm

Heat Treatment:TMCP/Normalised

BV EH36 steel plate,BV EH36 steel sheet,BV Grade EH36 shipbuilding steel price,BV Grade EH36 steel supplier and manufacturer.

BV EH36 Shipbuilding Steel Description:

All BV steels are standard carbon steels. All of these steels have been engineered to be optimal long-lived shipbuilding steels.As with other grades of steel, they have a specific gravity of 7.8.Higher-strength BV shipbuilding steel comes in six grades of two strengths, The BV EH36 grades have yield strength of 51,000 psi (355 MPa), and ultimate tensile strength of 71,000 – 90,000 psi (490-620 MPa).

BV EH36 Shipbuilding Steel Application:

BV EH36 Shipbuilding steel plates are suitable for container and bulk cargo vessels as well as cruise ships, ferries and yachts.



BV EH36 Equivalent steel grade

Equivalent steel grade of BV EH36

DNV

GL

LR

BV

CCS

NK

KR

RINA

NV E36

GL-E36

LR/EH36

BV EH36

CCS/E36

K E36

R E36

RI/E36

Specification Parameters
Basic Information

BV/EH36 high Strength Chemical Composition in Tempering and Quenching

Grade

The Element Max (%)

C

Si

Mn

P

S

Al

N

BV/EH36

0.18

0.1-0.50

0.90-1.6

0.035

0.035

0.015

Nb

V

Ti

Cu

Cr

Ni

Mo

0.02-0.05

0.05-0.10

0.02

0.35

0.2

0.4

0.08

Crack Sensitivity:  Pcm = (C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent:  Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%



BV/EH36 high strength property in tempering and quenching

Grade

Mechanical Property

Charpy V Impact Test

Thickness

Yield

Tensile

Elongation

Degree

Energy 1

Energy 2

BV/EH36

mm

Min Mpa

Mpa

Min  %

-40

J

J

t≤50

355

490-630

21%

24

34

50<t≤70

355

490-630

21%

27

41

70<t≤100

355

490-630

21%

34

50

Note: Energy 1 is transverse impact test, Energy 2 is longitudinal

Service Support
BV-AH36 shipbuilding steel plate

Technical Requirements & Additional Services for BV EH36 Steel Plate:

♦ High tension test
♦ Z-Test (Z15,Z25,Z35)
♦ Low temperature impacting test
♦ Ultrasonic test under ASTM A435,A577,A578
♦ Cetificated by ABS,LR,GL,BV,DNV,KR,NK,CCS,RINA
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting,Cutting and welding as per end user’s demands
