BV Grade EH32 Shipbuilding Steel Plate

BV EH32 shipbuilding steel plates and sheets have been exported to worldwide shipyard and ship building company,we have mill BV Grade EH32 for shipbuilding.If you have any needs in BV Grade EH32 steel plate price and suppliers, please feel free to contact us.

Grade BV EH32, BV EH32 steel, BV EH32 steel plate, BV EH32 steel sheet, BV EH32 shipbuilding steel price, and BV EH32 steel supplier and manufacturer.

BV EH32 shipbuilding Steel Description:

All BV steels are standard carbon steels. As with other grades of steel, they have a specific gravity of 7.8. Higher-strength BV shipbuilding steel comes in 12 grades of 3 strengths, EH32 is one of the grades.The BV EH 32 grade steel plates have yield strength of 45,500 psi (315 MPa), and ultimate tensile strength of 64,000 – 85,000 psi (440-590 MPa).

BV EH32 Shipbuilding Steel Application:

BV EH32 Shipbuilding steel plates are mainly used for making the hull of ship building and ship repairing, the offshore oil drilling platform, the platform pipe joints and other components.



Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Specification Parameters
Basic Information

BV EH32 Shipbuilding Steel Chemical Composition:

Grade

C %

Si %

Mn %

P %

S %

V %

AL %

Cr %

BV Grade EH32

0.180

0.1-0.5

0.90-1.6

0.035

0.035

0.05-0.10

0.015

0.200

Cu %

Mo %

Nb %

Ni %

Ti %

0.350

0.080

0.02-0.05

0.400

0.020



BV EH32 Grade Ship Steel Mechanical Properties:

Grade

Thickness(mm)

MinYield(Mpa)

Tensile(Mpa)

Elongation (%)

Min Impact Energy

BV Grade EH32

8mm-50mm

Min 315Mpa

440-590Mpa

22

-40

34J

51mm-70mm

Min 315Mpa

440-590Mpa

22

-40

38J

71mm-100mm

Min 315Mpa

440-590Mpa

22

-40

46J

The minimum impact energy is longitudinal energy
