CCS Grade DH36 Shipbuilding Steel Plate

Steel Standard:China Classification Society

Rolling Type:Shipbuilding steel plate,High tension ship plate

Thickness:3mm-300mm

Width:1200mm-4200mm

Length:3000mm-18000mm

Heat Treatment:TMCP/Normalised

CCS Grade DH36 Shipbuilding Steel Plate Supplier

Normalized shipbuilding steel plate CCS Grade DH36 is a higher steel grade among shipbuilding steel.When rolling CCS Grade DH36,CCS DH36,CCS DH36 steel plate, TMCP or Normalized shall be done for heat treatment.Low temperature impacting test have to be done under minus 20 centigree for ship steel plate CCS Grade DH36.For improve the thickness-direct steel property for shipbuilding steel plate CCS Grade DH36,Z-test for CCS Grade DH36 is also necessary,our customers can choose three different classes,Z15,Z25 and Z35.



Specification Parameters
Basic Information

Mechanical property for CCS Grade DH36 shipbuilding structual steel:

Yield strength (≥Mpa) Tensile strength (Mpa) Elongation in ≥,%
355 490-620 200mm 50mm
19 22

Chemical composition for CCS Grade DH36 ship steel (Heat Analysis Max%)

Main chemical elements composition of CCS Grade DH36
C Si Mn P S Al (acid) min. Nb
0.18 0.10-0.50 0.90-1.60 0.035 0.035 0.015 0.02-0.05
V Ti Cu Cr Ni Mo
0.05-0.10 0.02 0.35 0.20 0.40 0.08

What is the equivalent steel grade of CCS/DH36?

Equivalent steel grade of CCS/DH36

DNV

GL

LR

BV

ABS

NK

KR

RINA

NV D36

GL-D36

LR/DH36

BV/DH36

ABS/D36

K D36

R D36

RI/D36

Service Support
CCS Grade DH36 Shipbuilding Steel Plate

Technical Requirements & Additional Services for CCS DH36 steel plate:

♦ High tension test
♦ Z-Test (Z15,Z25,Z35)
♦ Low temperature impacting test
♦ Ultrasonic test under ASTM A435,A577,A578
♦ Cetificated by ABS,LR,GL,BV,DNV,KR,NK,CCS,RINA
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting,Cutting and welding as per end user’s demands
