CCS Grade EH32 ship plate CCS Grade EH32 shipbuilding steel Supplier

Classification society:CCS China Classification Society

Thickness: 3mm-300mm

Width: 1200mm-4200mm

Length: 3000mm-18000mm

Heat Treatment:As rolled/Control-rolled/Hot rolled

CCS Grade EH32 ship plate CCS Grade EH32 shipbuilding steel Supplier

CCS EH32 shipbuilding steel plate is nromally used to build ships and vessels which sailed in ocean waters and the tough situiation. CCS Grade EH32 marine steel shall be done low temperature impacting test under minus 40 centigree when rolling.Minimum yield strength for shipbuilding steel plate CCS Grade EH32 is at 315 Mpa.

CCS EH32 shipbuilding steel plate, CCS Grade EH32 marine steel material Delivery States

CCS Grade EH32 marine steel is lower than FH32 in yield and tensile strength. It is a good material for shipbuilding in deck. EH32 Grade is in -40 impact test of 34J energy. All of thickness of EH32 material need normalize in delivery station. CCS Grade EH32 marine steel is mainly used to Shipbuilding Project and Ocean Offshore Structural Projects.



CCS EH32 shipbuilding steel plate Specification

Thickness: 3mm-300mm

Width: 1200mm-4200mm

Length: 3000mm-18000mm

Delivery Time: 30-50 days, 7 days for stock goods.

Loading Port: Shanghai ,Tianjin, Qingdao.

Offer Ability:5 000MT/Per Month.

Trade Terms: FOB, CFR or CIF

Specification Parameters
Basic Information

EH32 Marine Steel plate chemical composition (%)

Grade C max Si max Mn P max S max Als min Ti max Cu max Cr
max
Ni
max
Mo
max
EH32 0.18 0.50 0.90-1.60 0.035 0.035 0.015 0.02 0.35 0.20 0.40 0.08



EH32 shipbuilding steel plate Mechanical Property

Grade Rm
(MPa)
Re(MPa) min A% min Akv/J min
EH32 440-570 315 22 E.T °C Thickness (mm)
-40  50 >50-70 >70-100
L C L C L C
31 22 38 26 46 31



EH32 shipbuilding steel plate Condition Of Delivery

Grade Fine grains elements category The thickness of steel
≤ 12 >12.5-20 >20-25 >25-35 >35-50 >50-100
EH32 Any Plate/sheet N,TM
Profile steel N(25),TM(25),AR*(15),CR*(15)

Note: 1. delivery condition: A =Any ; N=Normalized ; CR=Control Rolled ; TM=TMPC, Temperature – deformation control rolling; AR*= Can be hot rolled with the agreement of Classification Society ; CR*=Can be control rolled with the agreement of Classification Society .
