Home > Steel Pipe> DIN 17175 17Mn4 Low Carbon Steel Tubes

DIN 17175 17Mn4 Seamless Steel Tubes For Elevated Temperatures Supplier

DIN 17175 Grade 17Mn4 Carbon Steel Seamless Tubes are also known as mild steel pipes and tubes. DIN 17175 Grade 17Mn4 Tubes, are low-cost Low Carbon Steel Tubes with 012 – 020 % carbon content with combination of 040 – 080 % manganese easy to form and shape . These pipes are manufactured as per DIN Specification and commercially referred as cs pipes or ms pipes.Low Carbon Steel Pipes are not as hard as hig carbon steel pipes,Though carburizing can increase its surface hardness.

17Mn4 Steel Pipe Application

DIN 17175 Seamless Steel Tubes are commonly used in gas, oil, chemical, petrochemical industries, particularly suited for manufacturing boiler, pressure vessel, heat exchangers, spheres, separators, nuclear reactor vessel, gas and oil tank, liquid oil storage, and hydraulic.



Specification Parameters
Basic Information

DIN 17175 Grade 17Mn4 Chemical Properties

Carbon Silicon Manganese Phosphorous Sulphur Molybdenum Nickel Chromium Copper Others
0.14 – 0.20 0.20 – 0.40 0.90 – 1.20 0.04 0.04 max 0.30

Mechanical Properties of DIN 17175 Grade 17Mn4 pipe

Yield Strength Tensile Strength Elongation A5 min
MPa min ksi min MPa min MPa min ksi min Percentage
460 580 23

DIN 17175 17Mn4 Equivalent Designation

DIN EN BS NFA ASTM ASME
DIN 17175 Grade 17Mn4 NFA A 49-213 Grade TU 48-c ASTM A106 Grade C ASME A 106 Grade C
Service Support
DIN 17175 17Mn4 Low Carbon Steel Tubes

Test

  • Chemical composition verification test
  • hydrostatictest
  • Tensile test
  • Notched impact test
  • Yield strength test
  • Ring test
  • Nondestructive testing

Package and Shipping

There are probably hundreds of different methods for packing a pipe, and most of them have merit, but there are two principles that are vital for any method to work prevent rusting and Sea transportation security.

  • Plastic caps plugged at the two sides of pipe ends
  • Should be avoided by the steel strapping and transport damage
  • Bundled signs should be uniform and consistent
  • The same bundle(batch) of steel pipe should be came from the same furnace.
  • The steel pipe has the same furnace number, the same steel grade, the same specifications.

Our packing can meet any needs of the customers.
