Hardox 450 Plates

Hardox 450 has a solid reputation as a highly versatile, abrasion-resistant steel that also has structural properties. With an extra 50 HBW hardness over AR 400 grades, it provides additional wear resistance for an extended service life. The hardness also increases the steel’s strength, with better dent resistance as a result. The high toughness also in cold conditions ensures that equipment can take impact forces without compromising its structural integrity.

Hardox 450 Wear Resistant Liner Plates Hardox 450 Wear Resistant Steel Plate Hardox 450 Plate Stockholder Hardox 450 Hot Rolled Plate Hardox 450 Cut Plates Hardox 450 Steel Plates Hardox 450 Abrasion Resistant (AR) Plates

What is  Hardox 450 Steel?

Hardox 450 steel is an abrasion resistant wear plate. Hardox steel is ideal for bodies that will be used for hauling very abrasive and high impact materials such as boulders, demo materials and medium to large aggregate.  450 Hardox has a yield strength of around 175,000 lbs minimum yield. That is 75% stronger than 100K steel, and 250% stronger than 50K steel. The strength of AR450 steel can improve weight savings over 50K much like 100K material because a thinner material can be used without sacrificing strength.

Hardox 450 Plates—Industries & Applications

Our Plates are used in a wide range of applications and various industries. Below are a few of them:
  • Excavators
  • Crushers
  • Bulldozers
  • Loaders
  • Knives
  • Cutting edges
  • Silvers
  • Feeders
  • Measuring Pockets
  • Skips
  • Shovels
  • Diggers
  • Graders

Hardox 450 Plate Processing

Processes on Hardox 450 Plates includes Shearing, Drilling, High Definition Plasma, Sawing, Oxy Cutting, Standard Definition Plasma, Forming, Laser and much more. We take great pride in not just offering great services for our customers, but we stand behind the services we provide in a way that is unmatched in the industry.

Cutting, Bending, Drilling, Milling, Punching, Forming, Hot Forming, Welding, Shearing

Specification Parameters
Specification Parameters

Hardox 450 Mechanical Properties

Grade Thickness Hardness 1) Tesnile strength Typical yield
(mm) (HBW) Rm strength
(MPa), (MPa), not
guaranteed guaranteed
Hardox 450 CR sheet 0.7 – 2.10 425 – 4752) 1370 – 1600 1250
Hardox 450 sheet 2.0 – 8.0 425 – 475 – 1250
Hardox 450 plate 3.2 – 80.0 425 – 475 – 1250
Hardox 450 plate 80.1 – 103.0 410 . 475 – 1250
Hardox 450 plate 103.1 – 130.0 390 . 475 – 1250

1) Brinell hardness, HBW, according to EN ISO 6506-1, on a milled surface 0.5 – 3 mm below surface. At least one test specimen per heat and 40 tons.

2) Hardness test is not performed or guaranteed for Hardox 450 cold rolled material. The hardness interval is a conversion from the tensile strength. The nominal thickness of supplied plates will not deviate more than +/- 15 mm from the thickness of the test specimen used for hardness testing.

Hardox is through-hardened. Minimum core hardness is 90% of the guaranteed minimum surface hardness.

Hardox 450 Sheet Chemical Composition (heat analysis)

Grade C*) Si*) Mn*) P*) S *) Cr*) Ni*) Mo*) B*)
(max %) (max %) (max %) (max %) (max %) (max %) (max %) (max %) (max %)
CR sheet 0.18 0.25 1.3 0.015 0.004 0.1 0.1 0.04 0.003
Sheet & plate 0.26 0.7 1.6 0.025 0.01 1.4 1.5 0.6 0.005
