LR AH32 DH32 EH32 FH32 Steel Plate

Steel Standard:LR (Lloyd’s Register)

Rolling Type:Shipbuilding steel plate,High tension ship plate

Thickness:3mm-250mm

Width:1200mm-4200mm

Length:3000mm-18000mm

Heat Treatment:TMCP/Normalised

LR AH32 DH32 EH32 FH32 Steel Plate Supplier and Manufacturer

Lloyd’s Register Grades AH32, DH32 and EH32 FH32 are higher-strength structural steels with a specified minimum yield strength of 46 ksi and specified minimum Charpy V-notch impact toughness properties.Marine steel plate refers to structural steel used in ship building. It is considered a marine grade and must be able to resist corrosive effects that are common in a water environment. To achieve this, special alloying elements are added to these grades in order to defend agaist corrosion.While most carbon steel is not suited for marine environments, there are several marine grade carbon steels that have been approved by the different societies for shipbuilding applications.

Applications

Typical applications include ships and other structural applications.

Specification Parameters
Basic Information

LR AH/DH/EH 32 Steel Chemical composition

Steel grade C Si Mn P S Als
Grade AH32 ≤0.18 ≤0.50 0.9-1.6 ≤0.035 ≤0.035 ≥0.015
Grade DH32 ≤0.18 ≤0.50 0.9-1.6 ≤0.035 ≤0.035 ≥0.015
Grade EH32 ≤0.18 ≤0.50 0.9-1.6 ≤0.035 ≤0.035 ≥0.015
Grade FH32 ≤0.18 ≤0.50 0.9-1.6 ≤0.035 ≤0.035 ≥0.015

LR Shipbuilding Steel Plate Grade AH32 DH32 EH32 FH32 Mechanical Properties

Steel grade Yield point/MPa Tensile point /MPa Elongation/% Temperature/° C V-type impact test
Akv/J
≤50MM 50-70MM 70-100MM
Grade AH32 ≥315 440-570 ≥22 0 31/22 38/26 46/31
Grade DH32 ≥315 440-570 ≥22 -20 31/22 38/26 46/31
Grade EH32 ≥315 440-570 ≥22 -40 31/22 38/26 46/31
Grade FH32 ≥315 440-570 ≥22 -60 31/22 38/26 46/31
Service Support
LR AH32 DH32 EH32 FH32 Steel Plate

Other than LR AH32 steel, we also supply other LR shipbuilding steel materials:

LR grade A LR grade B LR grade D LR grade E
LR AH32 LR DH32 LR EH32 LR FH32
LR AH36 LR DH36 LR EH36 LR FH36
LR AH40 LR DH40 LR EH40 LR FH40
