Home > products> LR Grade EH32 Marine Steel Plate

LR Grade EH32 Marine Steel Plate

Steel Standard:LR (Lloyd’s Register)

Rolling Type:Shipbuilding steel plate,High tension ship plate

Thickness:3mm-250mm

Width:1200mm-4200mm

Length:3000mm-18000mm

Heat Treatment:TMCP/Normalised

LR EH32 shipbuilding steel plate LR EH32 shipbuilding sheet LR EH32 shipbuilding plate supplier LR EH32 shipbuilding plate price LR EH32 hull structure steel LR EH32 shipbuilding plate property

Introduction
Parameters
Service

What is LR Grade EH32 Marine Steel Plate?

The EH32 steel plate/sheet is the mainly kinds of steel for shipbuilding and oil platform. Shipbuilding grade EH32 is the high tensile strength steel with good toughness properties, higher strength, strong corrosion-resistance, the processing properties, and welding properties.

LR EH32 Shipbuilding Steel Application:

LR EH32 Shipbuilding steel plates are mainly used for making the hull of ship building and ship repairing, the offshore oil drilling platform, the platform pipe joints and other components.

Specification Parameters

Basic Information

LR EH32 high Strength Chemical Composition
Grade	The Element Max (%)
Grade	C	Si	Mn	P	S	Al	N
LR EH32	0.18	0.05	0.9-1.6	0.035	0.035	0.015
	Nb	V	Ti	Cu	Cr	Ni	Mo
	0.02-0.05	0.03-0.10	0.02	0.35	0.20	0.40	0.08

Crack Sensitivity: Pcm = (C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

LR EH32 high strength property
Grade		Mechanical Property			Charpy V Impact Test
Grade	Thickness	Yield	Tensile	Elongation	Degree	Energy 1	Energy 2
LR EH32	mm	Min Mpa	Mpa	Min %	-40	J	J
	t≤50	315	440-590	22%		20	31
	50＜t≤70	315	440-590	22%		26	38
	70＜t≤100	315	440-590	22%		31	46
Note: Energy 1 is transverse impact test, Energy 2 is longitudinal

Equivalent steel grade of LR EH32
DNV	GL	ABS	BV	CCS	NK	KR	RINA
NV E32	GL-E32	AB/EH32	BV/EH32	CCS/E32	K E32	R E32	RI/E32

Service Support

LR Grade EH32 Marine Steel Plate

Other than LR EH32 steel, we also supply other LR shipbuilding steel materials:

LR grade A	LR grade B	LR grade D	LR grade E
LR AH32	LR DH32	LR EH32	LR FH32
LR AH36	LR DH36	LR EH36	LR FH36
LR AH40	LR DH40	LR EH40	LR FH40
