LR Grade FH32 Shipbuilding Steel Plate

Steel Standard:LR (Lloyd’s Register)

Rolling Type:Shipbuilding steel plate,High tension ship plate

Thickness:3mm-250mm

Width:1200mm-4200mm

Length:3000mm-18000mm

Heat Treatment:TMCP/Normalised

What is LR FH32 steel plate?

LR FH32 steel plate for shipbuilding&platform. The shipbuilding steel plate grade FH32 is the high tensile strength steel. FH32 shipbuilding steel is the Hull structural steel,with it’s good toughness properties, higher strength,strong corrosion-resistance,the processing properties,and welding properties.



LR FH32 Shipbuilding Steel Application:

LR FH32 Shipbuilding steel plates can be used for producing container and bulk cargo vessels as well as cruise ships, ferries and yachts. LR FH32 Shipbuilding steel plates are mainly used for making the hull of ship building and ship repairing, the offshore oil drilling platform, the platform pipe joints and other components.

Specification Parameters
Basic Information

LR/FH32 high Strength Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

Al

N

LR/FH32

0.16

0.05

0.9-1.6

0.025

0.025

0.015

Nb

V

Ti

Cu

Cr

Ni

Mo

0.02-0.05

0.03-0.10

0.02

0.35

0.20

0.80

0.08

Crack Sensitivity:  Pcm = (C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent:  Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%



LR/FH32 high strength property

Grade

Mechanical Property

Charpy V Impact Test

Thickness

Yield

Tensile

Elongation

Degree

Energy 1

Energy 2

LR/FH32

mm

Min Mpa

Mpa

Min  %

-60

J

J

t≤50

315

440-590

22%

20

31

50<t≤70

315

440-590

22%

26

38

70<t≤100

315

440-590

22%

31

46

Note: Energy 1 is transverse impact test, Energy 2 is longitudinal



Equivalent steel grade of LR/FH32

DNV

GL

ABS

BV

CCS

NK

KR

RINA

NV F32

GL-F32

AB/FH32

BV/FH32

CCS/F32

K F32

R F32

RI/F32

Service Support
LR Grade FH32 Shipbuilding Steel Plate

Other than LR FH32 steel, we also supply other LR shipbuilding steel materials:

LR grade A LR grade B LR grade D LR grade E
LR AH32 LR DH32 LR EH32 LR FH32
LR AH36 LR DH36 LR EH36 LR FH36
LR AH40 LR DH40 LR EH40 LR FH40
