Fish Food Pet Feed Extruder

The feed extruder can produce feed particles that float on the water surface for a long time, and the equipment performance is very good and the degree of automation is high.

Reference Price: $1500
inquiry now

Fish Food Pet Feed Extruder

The Pet Feed Extruder is widely used to process all kinds of grains into high-grade aquatic floating feed pellets for fish, catfish, shrimp, and crab. It can also make pet feed for dogs, cats etc, with different shapes and chicken feed.

Fish feed extruder machine sale

Make a quick inquiry now!

How Does a Fish Feed Extruder Work?

The raw material is evenly fed into the screw extrusion chamber of the fish food extruder by the feeder, and the volume of the extrusion chamber is gradually reduced in the direction of material flow, and the expansion pressure of the material is gradually increased. In this case, the movement of the material in the extrusion chamber is accompanied by strong shear and friction.

Sometimes, depending on the need, an electric heating sheet can be added on the outside of the expansion chamber to facilitate heating. This combined action will cause the temperature of the material to rise sharply and the starch in the material to gelatinize.

By the time the material came out of the mold hole, the pressure suddenly dropped to 0.1 MPa, the water quickly turned into steam and its volume increased, so the volume of the material also increased. The steam is further released and reduces the moisture content of the material, and the temperature drops rapidly. The material then solidifies immediately and forms many micropores in the condensed colloidal material.

Continuously extruded columnar or flaky air products are cut with a rotary cutter and cooled, sometimes post-drying and spraying procedures of additives (such as fat, vitamins, etc.) are also necessary.

Fish Feed Machine process

Features of Fish Food Pet Feed Extruder

1. The floating fish feed machine can make pellets from a diameter of 1 mm to 12 mm just by changing the mold.
2. An electric heating device is adopted, which can improve the feed expansion rate and pellet floating time.
3. High-temperature and high-pressure cooking processes can wipe out salmonellosis and bacterial infections and also make the pellets easy to digest.
4. The cutting device can be adjusted to make pellets of different lengths
5. The extruder design is unique; the structure is simple, easy to install, easy to disassemble, and easy to operate.
6. The floating time can be controlled by the puffing degree adjustment
7. The finished pellets can keep floating for 3-15 hours without polluting the water.
8. An electric heating device is adopted, which can improve the feed expansion rate and pellet floating time.
9. The wet type machine needs a boiler to make steam, which can conduct steam to the conditioner and ripen the raw material in advance.

Raw Material

The raw material is: Flour, corn meal, soybean meal, maize meal, meat meal, bone meal, fish meal, etc.

Fish Feed Machine price

Mold Hole And Finished Product Display

The feed extruder comes with several different matrices (pillows, hearts, balls, etc.), which allows you to produce feed of various shapes. Moreover, due to the cutting knives, the size of the final product can be controlled from 1 to 20 mm. The device automatically controls the raw material feed speed and volume. Both can be adjusted during operation.

Best fish food extruder machine



Orders Ready for Shipment

Floating Fish Food Pet Food Extruder

Specification Parameters
Basic Information
Model Capacity Screw Diameter Main Power Feeding Power Cutting Power
MK-40 30-40kg/h 40mm 5.5kw 0.4kw 0.4kw
MK-50 60-80kg/h 50mm 11kw 0.4kw 0.4kw
MK-60 120-150kg/h 60mm 15kw 0.4kw 0.4kw
MK-70 180-250kg/h 70mm 18.5kw 0.4kw 0.4kw
MK-80 300-350kg/h 80mm 22kw 0.4kw 0.6kw
MK-90 400-450kg/h 90mm 37kw 0.4kw 1.5kw
MK-120 500-700kg/h 120mm 55kw 0.4kw 2.2kw
MK-135 700-800kg/h 133mm 75kw 0.4kw 2.2kw
MK-160 1200-1500kg/h 155mm 90kw 0.75-1.1kw 3.0kw
MK-200 1800-2000kg/h 195mm 132kw 1.5kw 3.0-4.0kw
