Core Functions & Product Advantages

1. Low-Speed High-Torque Output for Heavy Implement Driving As the core reduction gear of the PTO system, it meshes with the driving gear to achieve 2-3 times torque amplification, providing low-speed power output such as 540 rpm, which perfectly matches the high-torque driving requirements of heavy agricultural implements such as rotary tillers, subsoilers, seeders and straw returners. It is the key power transmission component for tractors in this horsepower range to achieve efficient field operations.
2. Dual-Speed PTO Switch for Multiple Working Conditions It forms a dual-speed PTO system with the high gear driven gear, realizing high-low speed switching through the shifting mechanism. The low gear is suitable for heavy-duty operations such as deep plowing and deep loosening, while the high gear is suitable for light-load high-speed operations such as transportation and plant protection, greatly improving the operational adaptability and versatility of the tractor.
3. Stable Power Transmission for Continuous Operation Adopting high-precision involute tooth profile design, multi-tooth simultaneous meshing ensures stable transmission and low noise. It can stably withstand alternating loads and impacts during implement operation, eliminate tooth breakage and jumping failures, and ensure the reliability of long-term continuous operation.
4. High Strength & Wear Resistance for Harsh Field Conditions Made of high-quality alloy structural steel 20CrMnTi/40Cr, and treated by carburizing and quenching, the tooth surface hardness reaches HRC56-60, with hard surface and tough core, strong wear resistance. It can adapt to harsh field environments such as mud and dust, extend service life and reduce maintenance costs.
5. High-Precision OEM Matching & Easy Installation Produced in strict accordance with OEM specifications, the tooth profile, module, number of teeth and mounting hole position are 1:1 matched with the original vehicle PTO system. No secondary modification is required, it can directly replace the original parts, with strong interchangeability and convenient installation, compatible with most mainstream brands of 100-120HP tractors at home and abroad.

Product Structure & Manufacturing Process

• Main Structure Type: Standard single PTO low gear driven gear (suitable for most models), optional double gear (integrated with high gear), compact structure, saving gearbox space and more convenient shifting.
• Tooth Profile Design: Adopting national standard involute cylindrical spur/helical teeth, complying with the industry standard of tractor transmission system; tooth profile modification design to reduce meshing impact and improve bearing capacity, specially optimized for agricultural implement driving conditions.
• Core Manufacturing Process: High-quality round steel cutting → Forging → Normalizing Treatment → Precision CNC Hobbing/Gear Shaping → Carburizing Quenching → Precision Grinding → Magnetic Particle Inspection → Blackening/Phosphating Anti-Rust Treatment.
• Accuracy Grade: ISO Grade 7-9, in line with the industry accuracy standard of agricultural machinery transmission parts, with precisely controlled meshing clearance, stable transmission and low noise.

Application Fields & Working Scenarios

1. Core Application Field Exclusively suitable for 100-120HP agricultural wheeled tractors, covering mainstream brands at home and abroad such as YTO, Foton Lovol, John Deere, Case New Holland, Dongfeng Agricultural Machinery in the same horsepower range. It is the standard core transmission part and high-frequency replacement wearing part of tractors in this horsepower range.
2. Core Working Scenarios Rotary tillage, harrowing, sowing and fertilization operations of field crops such as wheat and corn in the North China/Huazhong Plain of China; deep loosening, land preparation and straw returning operations in the black soil of Northeast China; intertillage, ditching and ridging operations in orchards and vegetable greenhouses; farm material transportation and small construction machinery traction operations.
3. Extended Application Fields Wheel loaders, graders, combine harvesters, self-propelled silage machines and other agricultural engineering machinery in the same power range; auxiliary power take-off systems of small mining and forestry operation vehicles.

Purchase Notes

1. Compatibility Instruction: Please provide the tractor brand and model, OEM part number, product drawing or sample when placing an order. We can accurately match the corresponding products, and support non-standard customization according to your drawings and samples.
2. MOQ Requirement: Small batch purchase is available for in-stock items, MOQ for customized items is negotiable according to your demand, OEM/ODM service is supported.
3. Quality Assurance: All products have passed multiple tests of hardness, meshing accuracy and magnetic particle inspection before delivery, fully complying with the industry quality standards of agricultural machinery, and providing perfect after-sales warranty service.
4. Logistics & Delivery: In-stock orders will be shipped within 48 hours, delivery time for customized items is negotiable according to the production cycle. We support nationwide logistics distribution and cross-border foreign trade sea/air freight.

FAQ

1. Is this PTO low gear driven gear compatible with my 110HP tractor? A: Yes, our products are specially designed for 100-120HP tractors. Just provide the tractor brand, specific model or OEM part number, we will match the fully compatible products for you. We also support non-standard customization according to your drawings and samples.
2. How about the service life of the product? Is it suitable for long-term heavy-duty operation? A: This product is made of high-quality alloy steel with precision processing and carburizing quenching process. Under normal working conditions, its service life can match or even exceed OEM parts. It is specially optimized for heavy-duty working conditions such as rotary tillage and deep loosening, and can withstand high-frequency impact load for a long time with strong durability.
3. Can the material of the gear be customized? A: Yes, we standardly use 20CrMnTi alloy structural steel, and can also customize higher strength materials such as 40Cr and 42CrMo according to your working condition requirements. At the same time, we can adjust the tooth profile and heat treatment process to meet personalized use needs.
4. Can it be installed directly after receipt? Is secondary modification required? A: Our products are produced in strict accordance with OEM 1:1 parameters, the installation size and tooth profile parameters are fully matched with the original vehicle. It can directly replace the original parts after receipt, without any secondary modification, and is easy to install.
