Home > products> Q890 High strength steel

Q890 High strength steel

GB/T16270 Q890C , Q890D , Q890E , Q890F

Thickness :5-200mm

Width:1000mm 1220mm 1250mm 1500mm 2000mm

Surface:Clean, blasting and painting according to customer requirement

Q890 High strength steel Q890 plate GB/T 16270 High Strength Plate Q890C steel plate Q890E quenched tempered Steel plate

Introduction
Parameters
Service

Q890 High strength steel

High strength steel is a type of alloy steel that provides better mechanical properties and greater resistance to corrosion than conventional carbon steel. High strength steels are steels with yield strength levels in excess of 550 MPa.It is used in bridge building, mining, crane construction, mechanical engineering, safety constructions and in the offshore industry. As high-strength steel is available from very thin sheet thicknesses, it is also used in the automotive industry.

GB/T16270 Q890C , Q890D , Q890E , Q890F

Specification

Product Detailes	HIGH STRENGTH Q890
COMMODITY	Hot rolled steel plate/Mild steel plate/black steel plate/Carbon steel plate/sheet
STEEL GRADE	ASTM A516 GR60 GR70,A516 GR60N,GR70N
Standard	GB,JIS,DIN,AISI,ASTM
Thickness	5-200mm
Width	1000mm 1220mm 1250mm 1500mm 2000mm
length	below 12000mm
Surface	Clean, blasting and painting according to customer requirement
Delivery time	standard size 15days goods can load into container, if produce goods need 35days
Application	Widely used in petrochemistry,chemistry,electricity,boiler and vessel manufacture,and could be made into reactor,heat exchange facility,segregator,sphere vessel,oil tank,liquid gas storage tank,nuclear
Shipping	length below 5.8m with 20′ container, length below 11.8m with 40′ container. or Bulk shipping

Specification Parameters

Basic Information

GB Q890 Chemical Composition

Element	Composition (%)
Carbon (C)	≤ 0.20
Manganese (Mn)	1.00 – 1.70
Silicon (Si)	0.15 – 0.60
Phosphorus (P)	≤ 0.025
Sulfur (S)	≤ 0.015
Chromium (Cr)	0.30 – 1.50
Nickel (Ni)	0.30 – 2.00
Molybdenum (Mo)	0.15 – 0.70
Copper (Cu)	≤ 0.50
Aluminum (Al)	0.015 – 0.060
Vanadium (V)	0.02 – 0.20
Niobium (Nb)	0.015 – 0.060
Titanium (Ti)	0.006 – 0.050
Boron (B)	0.0005 – 0.0050

GB Q890 Mechanical Properties

Property	Value
Yield Strength (Rp0.2)	≥ 890 MPa
Tensile Strength (Rm)	940 – 1180 MPa
Elongation (A5)	≥ 14%
Impact Energy (KV2) at -40°C	≥ 27 J
Impact Energy (KV2) at -60°C	≥ 20 J
Brinell Hardness (HBW)	280 – 360
Young’s Modulus	210 GPa
Poisson’s Ratio	0.30
Fatigue Limit (10^7 cycles)	400 MPa
Fracture Toughness (KIC)	120 MPa·m^0.5
Reduction of Area	≥ 50%

GB Q890 Physical Properties

Property	Value
Density	7.85 g/cm³
Melting Point	1450 – 1520°C
Thermal Conductivity (20°C)	42 W/m·K
Thermal Expansion Coefficient (20-100°C)	12.5×10^-6/K
Thermal Expansion Coefficient (20-200°C)	13.0×10^-6/K
Specific Heat Capacity	460 J/kg·K
Electrical Resistivity (20°C)	0.18 µΩ·m
Magnetic Permeability	Ferromagnetic
Curie Temperature	770°C
Thermal Diffusivity (20°C)	11.6 mm²/s
