ABS EQ63/ABS E63 Marine Steel Plates Suppliers and Manufacturers

Class Cert.: ABS/BV/CCS/DNV/KR/LR/NK/RINA/RS/PRS

Material: Low Alloy Steel

Thickness: 6mm-100mm, or customized

Width: 900mm-4800mm, or customized

Length: 3000mm-25000mm, or customized

Condition of Delivery: A/HR/N/CR/Q+T/TMPC, or as request

Stock: In stock

ABS EQ63 steel ABS EQ63 STEEL PLATE AB EQ63 Shipbuilding Steel Plate AB EQ63 Steel Plate Suppliers and Manufacturers ABS Grade EQ63 Shipbuilding steel plate ABS Grade EQ63 Ship Steel plate ABS Grade EQ63 Marine Steel plate ABS Grade EQ63 Steel Plate

Introduction
Parameters
Service

What are ABS EQ63 and ABS E63?

ABS EQ63 and ABS E63 are high-strength steel plates specifically designed for use in marine construction and shipbuilding. These grades adhere to the strict standards set by the American Bureau of Shipping (ABS) for ensuring the safety and durability of vessels at sea.

Specifications of AB EQ63 Shipbuilding Steel Plate

Project	Data
Steel Grade	AB/EQ63
Chemical Composition	C %	≦0.20
	Si %	≦0.55
	Mn %	≦1.70
	P %	≦0.025
	S %	≦0.025
	N %	≦0.020
Mechanical Property	Upper Yield strength (ReH/MPa)	≧620
	Tensile Strength (Rm/MPa)	720~890
	Elongation after Fracture (A/%)	≧15
	Test Temperature (℃)	-40
Heat Treatment	TM/QT/TM+T
Plate Size	Thickness (mm)	6~350
	Width (mm)	900~4850
	Length (mm)	3000~25000
Notes	It is available to customize the size of steel plate.

Specification Parameters

Basic Information

ABS EQ63 Extra high Strength Chemical Composition in Tempering and Quenching
Grade	The Element Max (%)
Grade	C	Si	Mn	P	S	N
ABS EQ63	0.20	0.55	1.7	0.030	0.030	0.02

Crack Sensitivity: Pcm = (C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

ABS EQ63 Extra high strength property in tempering and quenching
Grade	Mechanical Property			Charpy V Impact Test
	Yield	Tensile	Elongation	Degree	Energy 1	Energy 2
	Min Mpa	Mpa	Min %	-40	J	J
ABS EQ63	620	720-890	15	-40	41	62
Note: Energy 1 is transverse impact test, Energy 2 is longitudinal
