EN 10155 Steel Plate

Grade: S355K2G2W,S355K2G1W,S355J2G2W,S355JOW,S235J2W and so on

Type :steel plate

Standard: EN 10155

Steel Plate Thickness: 2-460mm

Steel Plate Width: 1500-3200mm

Length:6000-12000mm

Introduction
Parameters
Service

EN 10155 Steel Plate Supplier

EN 10155 provides structural steels with improved atmospheric corrosion resistance-Ttechnical delivery conditions,EN 10155 main steel grade:S355K2G2W,S355K2G1W,S355J2G2W,S355JOW,S235J2W and so on.

EN 10155 Steel Plate Chemical Composition

Grade	C (Max, %)	Si (Max, %)	Mn (%)	P (%)	S (Max, %)	Cr (%)	Cu (%)	Ni (Max, %)	V (%)	Nb (%)	Al (Min, %)
S355K2G2W	0.16	0.5	0.50-1.50	0.035	0.035	0.40-0.80	0.25-0.55	–	–	–	–
S355K2G1W	0.16	0.5	0.50-1.50	0.035	0.035	0.40-0.80	0.25-0.55	–	–	–	–
S355J0WP	0.12	0.75	≤1.0	0.06-0.15	0.04	0.30-1.25	0.25-0.55	–	–	–	–
S355J2G2W	0.16	0.5	0.50-1.50	0.035	0.035	0.40-0.80	0.25-0.55	0.65	0.02-0.12	0.015-0.060	0.02
S355J2G1W	0.16	0.5	0.50-1.50	0.035	0.035	0.40-0.80	0.25-0.55	–	–	–

EN 10155 Steel Plate Mechanical properties

Grade	Thickness (mm)	Min Yield Strength (MPa)	Tensile Strength (MPa)	Elongation Min (%)	Test Temperature (°C)
S355J2G1W	5 < t ≤16	355	490-630	22	—
	16 < t ≤40	345	490-630	22	—
	40 < t ≤63	335	490-630	21	—
	63 < t ≤80	325	490-630	20	—
	80 < t ≤100	315	490-630	20	—
S355J2G2W	—	355	510-610	22	—
S355J0WP	—	345	510-680	20	0
S355K2G1W（EN10155-1993）	t ≤16	355	t<3: 510-680；3≤t≤25.4: 490-630	1.5<<t≤2.0:16；2.0<<t≤2.5:17；2.5<<t<3.0:18；3≤t≤25.4:22	—
S355K2G1W（EN10155-1993）	16 < t ≤25.4	345	490-630	22	—
S355K2G1W	5 < t ≤16	355	490-630	20	—
	16 < t ≤40	345	490-630	20	—
	40 < t ≤63	335	490-630	19	—
	63 < t ≤80	325	490-630	18	—
	80 < t ≤100	315	490-630	18	—
S355K2G2W	5 < t ≤16	355	490-630	20	—
	16 < t ≤40	345	490-630	20	—
	40 < t ≤63	335	490-630	19	—
	63 < t ≤80	325	490-630	18	—
	80 < t ≤100	315	490-630	18
