EN10028-6 P690Q Pressure Vessel And Boiler Steel Plate

Thickness: 0.3-500mm

Width: 100-3500mm

Length: 1-12m,coil rolled,or as required

Surface Treatment: black pained,PE coated,Galvanized,Colour painted

Technique: Hot rolled,cold rolled

Delivery Condition：AR(As Hot Rolled), N(Normalized), T(Tempered), Q(Quenched), TMCP, Q+T(Quenched and Tempered), UT(Ultrasonic Test:ASTM A435,ASTM A578-C/B/A,EN10160-S0E1,S1E2,S2E3,S3E4), Impact Test, PWHT(Post Weld Heat Treatment), HIC, Z Test(Z15, Z25, Z35)

EN10028-6 P690Q Pressure Vessel Steel Plate EN10028-6 Grade P690Q Steel Plates EN10028-6 P690Q Boiler steel plate EN10028-6 P690Q Pressure Vessel Steel plate EN10028-6 P690Q Storage Tanks Steel plate EN10028-6 P690Q Heat Exchanger Steel Plate

Introduction
Parameters
Service

What is EN10028-6 P690Q Steel?

EN10028-6 P690Q is a pressure vessel steel grade that is widely recognized for its exceptional strength and durability, making it suitable for applications in the most demanding environments. This grade is part of the European standard for flat products for pressure equipment, and it is particularly valued for its ability to withstand high pressures and temperatures.

EN10028-6 P690Q Pressure Vessel And Boiler Steel Plate Application

EN10028-6 P690Q Pressure Vessel And Boiler Steel Plate are used in Pressure Vessel,Boiler,Storage Tanks and Heat Exchanger in Oil,Gas Project.

Specification Parameters

Basic Information

Chemical composition for P690Q pressure vessel steel plate (Max% ):

Steel Grade	The Main Elements in rolling P690Q pressure vessel steel plates
Steel Grade	C	Si	Mn	P	S	N	B
P690Q	0.20	0.80	1.70	0.025	0.015	0.015	0.005
	Mo	Cu	Nb	Ni	Ti	V	Cr
	0.70	0.3	0.06	2.50	0.05	0.12	1.50
