JIS G3114 SMA490BP Weather Resistant Steel Plate

Steel Standard:JIS G3114

Rolling Type:Corten steel,Weathering steel plate

Thickness:2mm-300mm

Width:1000mm-4200mm

Length:3000mm-18000mm

Heat Treatment:AR,CR.TMCP,Normalized

What is JIS G3114 SMA490BP steel?

Hot rolled atmospheric corrosion resistance steel plate SMA490BP,Hot rolled atmospheric corrosion resisting steel coil SMA490BP.Weather resistant steel materials SMA490BP,SMA490BP steel plate,SMA490BP steel sheet under steel standard JIS G3114.”Weathering” means that due to their chemical compositions, these steels exhibit increased resistance to atmospheric corrosion compared to other steels. This is because the steel forms a protective layer on its surface under the influence of the weather.

JIS G3114 SMA490BP Steel Plate Application

JIS G3114 standard specifies SMA400AW hot rolled atmospheric corrosion resisting steels for bridges, architecture and other welded structure. JIS G3114 SMA490BP atmospheric corrosion resisting steel is widely used in air preheater, economizer, railway carriage, containers production, bridge building , construction and so on.

Specification Parameters
Basic Information

Mechanical property for SMA490BP steel plate:

Thickness (mm)
SMA490BP ≤ 16 > 16 ≤ 40 > 40 ≤ 75 > 75 ≤ 100 > 100 ≤ 160 > 160
Yield strength (≥Mpa) 365 355 335 325 305 295
Tensile strength (Mpa) 490-610

Chemical composition for SMA490BP steel plate (Ladle Analysis Max%)

Main chemical elements composition of SMA490BP steel plate
C Si Mn P S Cu Cr Ni
0.18 0.55 1.40 0.035 0.035 0.20-0.35 0.30-0.55
