TBT 1979 09CuPCrNi-A weather resistant steel plate sheet

09CuPCrNi-A is a weather resistant steel made by alloying copper, chromium and nickel. 09CuPCrNi-A has added phosphorous, which makes it best suited for gas flue applications and for aesthetic facias.

What is TBT 1979 09CuPCrNi-A steel plate?

09CuPCrNi-A is a weather resistant steel made by alloying copper, chromium and nickel. 09CuPCrNi-A has added phosphorous, which makes it best suited for gas flue applications and for aesthetic facias.TB/T 1979 09CuPCrNi-A atmospheric corrosion resistant steel plates are widely used corten steel materials.GNEE steel supply 09CuPCrNi-A steel plates to users to make steel structures, such as railways, vehicles, bridges and towers, which are exposed to the atmosphere for a long time.TB/T 1979 09CuPCrNi-A atmospheric corrosion resistant steel plates are widely used for the manufacture of containers, railway vehicles, oil derrick, seaport building, oil production platform and chemical oil equipment containing hydrogen sulfide corrosion medium containers and other structural parts.



Specification of TBT 1979 09CuPCrNi-A steel plate

Thickness

1.2-20mm

Width

≤ 2000mm

Length

Customized

Equivalents of TBT 1979 09CuPCrNi-A steel plate

Warning! Only for reference

China

Japan

EU

Germany

France

England

European old

Italy

Inter

GB

JIS

EN

DIN,WNr

AFNOR

BS

EN

UNI

ISO

09CuPCrNi-A

SPA-H

S355J0WP
(1.8945)

9CrNiCuP324

E36WA3

WR50A

Fe510C1KI

Fe510C1K1

Fe355W-1A

            S355JOWP
Specification Parameters
Basic Information

Chemical composition of TBT 1979 09CuPCrNi-A steel plate

C max

Si

Mn

P

S max

Cu

Cr

Ni

0.12

0.25-0.75

0.20-0.50

0.060-0.120

0.02

0.25–0.50

0.30-1.25

0.12-0.65



Mechanical property of TBT 1979 09CuPCrNi-A steel plate

Grade

Thickness

Yield

Tensile

Elongation

Delivery state

09CuPCrNi-A

mm

Min Mpa

Mpa

Min %

4<

345

480

24

Hot rolling

≤ 4

310

440

26

Cold rolling
