Hardox® 500 Wear Plate

Hardox® 500 Plate is an abrasion-resistant steel plate with a hardness of 500 HBW. It’s also known for its high strength, excellent formability and weldability. It offers superior protection in harsh environments, making it ideal for applications such as dump bodies, excavators and crane buckets.

Hardox Wear Plates Abrasion Resistant Plate Wear Resistant Steel Plate cold rolled steel plate

Introduction
Parameters
Service

What is Hardox® 500 Steel Plate?

Hardox® 500 Tuf is an wear-resistant steel that offers both high performance durability and excellent formability. Hardox® 500 Tuf is the first 500 HBW wear plate with structural properties. It delivers extreme hardness and guaranteed toughness in a single wear plate. The material offers a 70–100% longer service life in comparison to conventional 400 HBW wear-resistant steel, and it includes improved dent protection. Hardox® 500 Tuf is available in thickness of 4 mm–25.4 mm and has a guaranteed impact strength of 27 J at -20°C in whole thickness range.

Applications of Hardox® 500 Plates

Hardox plates are designed for construction and mining equipments (excavators, dump trucks, bulldozers, hoppers, mixers, etc.).

as well as for machinery in very demand industries (recycling, agriculture, etc).
Screeners
Crushing and Pulverizing Equipment
Conveyors Belts
Grapples
Scrap Presses

Specification

Specifications: ASTM, ASME and API
Width: 1,500 mm to 2,500mm
Thickness: 4.0mm – 100mm
Finish: Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Specializes: Shim Sheet, Perforated Sheet, B. Q. Profile.
Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Condition: Cold Drawn & Polished Cold Drawn, Centreless Ground & Polished

Specification Parameters

Hardox® 500 Wear Plate Chemical Composition (heat analysis)

Product type	C *) (max %)	Si *) (max %)	Mn*) (max %)	P (max %)	S (max %)	Cr*) (max %)	Ni*) (max %)	Mo*) (max %)	B*) (max %)
Sheet	0.27	0.50	1.60	0.025	0.010	1.20	0.25	0.25	0.005
Plate	0.30	0.40	1.30	0.020	0.010	2.20	2.0	0.40	0.005

The steel is grain refined. *⁾ Intentional alloying elements.

Hardox® 500 Wear Plate Mechanical Properties

Product	Thickness (in)	Hardness 1) (HBW)	Typical yield strength (ksi), not guaranteed
Hardox® 500 sheet	0.079 – 0.275	470 – 530 2)	203
Hardox® 500 plate	0.157 – 1.260	470 – 530	203
Hardox® 500 plate	1.264 – 4.055	450 – 540	203

¹⁾ Brinell hardness, HBW, according to EN ISO 6506-1, on a milled surface 0.019 – 0.118″ below surface. At least one test specimen per heat and 40 tonnes. The nominal thickness of supplied plates will not deviate more than +/- 0.590″ from the thickness of the test specimen used for hardness testing. For sheet the Brinell hardness test is according to EN ISO 6506-1 on each heat treatment individual/coil. Hardness is measured on a milled surface 0.012 – 0.079″ below surface.

²⁾ Hardness test is not performed or guaranteed for Hardox® products with thicknesses < 0.098″. The tabulated hardness values for thickness < 0.098″ is a conversion from the tensile strength.
For more information please see the datasheet 2067- Hardness conversion of thin Hardox® wear sheet.

The nominal thickness of supplied plates will not deviate more than +/- 0.598″ from the thickness of the test specimen used for hardness testing.

Hardox^® wear plate is through-hardened. Minimum core hardness is 90 % of the guaranteed minimum hardness.
